Fusion E
Up to 6.4 km/h
86 kg
Rear wheel drive with high functionality
The Fusion E is a cost effective rear wheel drive power chair with a modular state of the art design that provides improved obstacle climbing performance and a smooth ride.
The Fusion E is a versatile chair that will meet the demands of even the most active user.
Specifications
| Weight Capacity | 23 St 6 lbs (150 kg) |
|---|---|
| Maximum Speed | 4 mph (6.4 km/h) |
| Ground Clearance | 40 mm (1.57 ") |
| Overall Length | 1050 mm (41.33") |
| Overall Width | 630 mm (24.8") |
| Turning Radius | 641.5 mm (25.25") |
| Total Weight (without batteries) | 86 kg |
| Tyres | Front: 245 mm (10”) solid front Rear: 355 mm (14”) solid |
| Suspension | Independent rear suspension |
| Battery Requirements | 2x 50 Ah Deep - Cycle |
| Battery Weight (each) | 17 kg |
| Note | 1. Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or - 3 %. 2. Specification varies with user weight, terrain, battery type, battery condition and tire pressure. 3. Battery weight may vary based on manufacturer. Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%. The information contained herein is correct at the time of publication; we reserve the right to alter specifications without prior notice. |
Overview
Download our
product brochure
Download our product brochure here to get an overview of our latest product range!
Features
- Independent Rear Wheel Drive System- Provides great control even at fast speeds and offer excellent stability even on rough terrain.
- Weight capacity of up to 23st 6lbs
- Travel up to 4mph
- Compatible with accessories such as the tablet holder, transfer bars, oxygen holder and hydration system
